In the past, I’ve measured the scan time of electronic shutters by photographing an analog oscilloscope trace of the output from a function generator. That was effective, but it took a while to set up and was a difficult experiment for some people to understand. So when I tested the scan time for the Z7 this morning, I used a quick-and-dirty method: photographing light from an LED that’s modulated at 120 Hz. I used single shot losslessly compressed raw at 1/2500 second shutter speed.
Because the light is modulated at 120 Hz, the stripes are 8.33 milliseconds apart. We can count them and see that there are a bit more than seven stripe intervals from the bottom to the top. So, the scan time is a bit over 60 milliseconds or about 1/16 second. This is the same as the D850 and Sony a7III.
The above test was done with the camera set for 14-bit raw. Marianne Oelund has measured the scan time for 12-bit raw at 1/20 second.
Jim, how does that sensor scan rate relative to other sensors besides the ones you mentioned?
Somehow 1/16 seems slow (to a layman). I would have thought faster.
It’s 1/50 on m43 E-M1 Mark II. The flash sync speed when doing pixel shift Hi-Res is 1/50 as well. And as expected it’s only 1/13 on A7RIII.
My my, counting fringes now? Considering a second (third?) career in optics, Jim?
