Fujifilm GFX 100 II — deep shadow noise at 14 and 16 bit precision

October 6, 2023 JimK Leave a Comment

This is the sixteenth post in a series of tests of the Fujifilm GFX 100, Mark II. You can find all the posts in this series by going to the Categories pane in the right hand panel and clicking on “GFX 100 II”.

Yesterday, I looked at the difference between deep shadow noise at ISO 80 and ISO 100 with the Fuji GFX 100 II. Today I’m examining the visual appearance of deep shadow noise at ISO 80 with 14 and 16-bit precision.

For this test, I mounted a 110 mm f/2 Fuji GF lens on the GFX 100 II, put the camera on a RRS tripod and C1 head, turned AF-S on for the initial exposure, switched to manual focus, and set an exposure that by the camera’s metering system, was 6 stops down from normal. Amazingly, the camera focused with the EVF almost totally black.

The rest of the particulars:

  • ISO 80
  • IBIS off
  • 14 and 16 bit precision
  • f/5.6 at 1/30 second
  • EFCS
  • Single shot drive mode

Developed in Lightroom, with default settings except:

  • 5-stop Exposure move
  • Shadows +100
  • Blacks +37
  • Noise reduction turned off
  • Sharpening amount 20 (default is 40)
  • White balanced to the white text in Hunt’s book on color

Here is the whole frame at both precisions.

14 bit precision



16-bit precision



Some crops at about 200% magnification.

14 bit precision



16-bit precision



14 bit precision



16-bit precision



14 bit precision



16-bit precision

I could convince myself that the 16-bit crops are a bit smoother, but it’s not something that will affect real world image quality.

As in the previous post, there are color shifts in the deep shadows. Those are due to inadequate black point calibration in Lightroom. I used the default calibration for these images. Custom calibration could remove most, if not all of the differences.
