Fuji 20-35/4 vs 32-64/4 landscape field curvature

October 7, 2022 JimK 2 Comments

I’ve received several requests to test the 20-35 against the 32-64 at 32 mm for field curvature.

I started with a tree 100 meters away in the center of the image.

20-35 GF at 32mm, center, f/4



32-64 GF at 32mm, center, f/4



I panned the camera so that the tree fell on the right side near the edge. I made pictures focusing in the center, and also without refocusing from the point where the tree was sharpest in the center. I made two sets of images, and picked the sharpest ones. The Fuji manual focusing at high magnification with peaking is good enough that both sets of images were about the same sharpness.

I used the side instead of the corner a) because it was easier,  and b0 because I thought it was more realistic for landscape photography, where the subject distance at the corners of the image is usually not the same as to the center.

Details:

  • GFX 100S
  • 2-second self timer
  • ISO 100
  • Manual focus
  • Low red peaking
  • Maximum magnification
  • RRS legs, C1 head
  • Developed in Lr CC with defaults except for
  • Adobe Standard Profile
  • Sharpening amount 20, radius 1, detail 25
  • Daylight color balance

Here are some crops at about 250% magnification.

20-35 GF at 32mm, center, f/4



32-64 GF at 32mm, center, f/4

The 32-64 is a little sharper.

20-35 GF at 32mm, edge, not refocused, f/4



32-64 GF at 32mm, edge, not refocused, f/4

The 20-35 is better.

20-35 GF at 32mm, center, f/5.6



32-64 GF at 32mm, center, f/5.6

About the same.

20-35 GF at 32mm, edge, not refocused, f/5.6



32-64 GF at 32mm, edge, not refocused, f/5.6

The 20-35 is better.

A reader suggested that the 32-64  f/5.6 edge picture above looks to blurry when compared to the f/4 image. I went back and dug up the other shot:

32-64 GF at 32mm, edge, not refocused, f/5.6

It’s a little better, but it’s still not quite as good as the 20-35.

20-35 GF at 32mm, center, f/8



32-64 GF at 32mm, center, f/8

About the same. The 20-35 has more contrast.

20-35 GF at 32mm, edge, not refocused, f/8



32-64 GF at 32mm, edge, not refocused, f/8

The 20-35 is better.

20-35 GF at 32mm, center, f/11



32-64 GF at 32mm, center, f/11

About the same.

20-35 GF at 32mm, edge, not refocused, f/11



32-64 GF at 32mm, edge, not refocused, f/11

The 20-35 is better.







GFX 100S

← Fujifilm 20-35/4 GF distortion Interim thoughts on the Hasselblad X2D 100C →

Comments

  1. Troy says

    October 7, 2022 at 12:36 pm

    Wow not what I guessed. Thanks again

    Reply
  2. Uwe says

    October 8, 2022 at 12:20 am

    Thanks, Jim!
    That’s a very interesting comparison. It looks to me that Fujifilm spent really big effort into the design of the 20-35.

    Reply
