Zeiss Batis 18/2.8 IR hotspotting

June 29, 2017 JimK 1 Comment

I’ve had a request to check the Batis 18 mm f/2.8 for infrared hotspotting. I used a Sony a7RII that has been modified by LifePixel with their “Standard IR” sensor filter.

I apologize for the fact that the images aren’t framed the same. The fog was burning off, I wanted to use it, and I didn’t have time to set up a tripod. Images all developed in Lightroom with +100 contrast boost and +20 highlight boost.

f/2.8



f/4



f/5.6



f/8



f/11



f/16

Hotspotting is present at all apertures including wide open.

This is not a good lens for infrared photography.



The Last Word

← Fuji 23 on GFX, Batis 18 on a7RII — distortion Fuji 23/4 on GFX, Nikon 14-24/2.8 on D810 →

Comments

  1. Oskar Ojala says

    July 7, 2017 at 3:26 pm

    Interesting to read this. I did recently try my Batis 25 for IR shooting, but it was poor: clear hotspotting and aberrations softening the whole image.
