Hasselblad 38/2.5 XCD on X2D, LoCA, natural scene

December 13, 2022 JimK 2 Comments

This is the 40th in a series of posts on the Hasselblad X2D 100C camera and the XCD lenses. You will be able to find all the posts in this series by looking at the righthand column on this page and finding the Category “X2D”.

I was asked recently to show how much longitudinal chromatic aberration (LoCA) there is with the Hasselblad 38 mm f/2.5 XCD lens on the Hasselblad X2D 100C. I pointed him to some tests I had done with foliage at 100 meters. He said he was looking for shots where the foliage was closer, and the sky was brighter in the image.

That’s what this post is about.

Here’s the scene, with the target foliage in the center and in the upper right corner.

Center, f/2.5



Corner, f/2.5

Setup:

  • Target distance 20 meters
  • RRS Legs, C1 head
  • Manual focusing, using X2D focus assist
  • 3 shots at each aperture and framing, picked the best one of the three in Lr
  • ISO 64
  • Various shutter speeds
  • Mechanical shutter

Development:

Lightroom with defaults except:

  • Sharpening amount = 20
  • +100 shadow boost

I’ll show you some 200% magnified crops:

Center, f/2.5

Pretty fuzzy.



Center, f/4

Quite a bit sharper. The branches aren’t as neutral as I’d like to see them, but this is not bad.

Center, f/5.6

Now it’s very sharp. Branches still have a little color to them.

Center, f/8



Center, f/11

There’s a little LoCA, but it’s not bad at all.

In the upper right corner:

Corner, f/2.5



Pretty ugly, but we knew that about this lens.

Corner, f/4

Better, but stil not very good.

Corner, f/5.6

Still a lot of LoCA.

Corner, f/8

Getting better.

Corner, f/11

Pretty good.

















X2D

← Using the Swebo TC-1 with more bellows extension Coming attraction →

Comments

  1. Tom Nuyts says

    January 2, 2023 at 2:10 am

    Dear Jim,

    ..are the Hassi Sensor PLUS (new) lenses really so un-sharp? I have in mind, that your processing is very extreme, but I remember so many pictures from Fuji GFX 50 and 100 MP plus lenses that were much cleaner and sharper

    am I wrong?

    best for the new year, Tom

    Reply
    • JimK says

      January 2, 2023 at 7:01 am

      So far, I only know about this XCD lens.

      Reply
