Coastal 60mm, Leica 50mm on a7R — right side

December 19, 2013 By JimK Leave a Comment

This continues an analysis of the Coastal Optical 60mm f/4 APO and the Leica 50mm f/1.4 Summilux ASPH on the Sony a7R. In the previous post we looked at the center. Now we examine the right side.

Along the right side of the image, the Coastal Optical lens is a little low in contrast at f/4.

60 ar7 4 rt

It picks up a little of both at f/5.6:

60 ar7 56 rt

And there’s a big step up in quality at f/8:

60 ar7 8 rt

f/11 is just the tiniest bit better yet:

60 ar7 11 rt

With the Summilux at f/4, the image is distinctly soft, and there’s that smeary look that I’m getting all too familiar with as I review the a7R:

50 ar7 4 rt

Stopping down to f/5.6 brings some improvement, but not nearly enough to catch the Coastal Optical lens:

50 ar7 56 rt

At f/8, things are better, even adequate for most purposes, but the Coastal Optical lens is still excelling:

50 ar7 8 rt

At f/11, diffraction is cancelling most of the smearing improvement brought by stopping down from f/8, and the quality is at best the same as the Coastal Optical lens wide open:

50 ar7 11 rt

Here’s a link to a Photoshop stack with all the images.

The Summilux would probably be fine for portraits on the a7R, but it wouldn’t be my first – or second – choice for landscapes.
